ECG Electrode

Key Benefits :

Highly conductive solid gel

Highly conductive hydro-gel

Latex Free PVC Free( in contact with skin)

Standard Ag/AgCl sensor

Flexible foam backing

Standard center stud connection

Radio Translucent and MRI compliant

Strong Adhesion

Fast catching ECG signal

Low impedance

Monitoring ECG

Item	Gel	Backing	Adhesive	Dimension	Usage
B1	Solid Gel	Foam	Enhanced	50*55mm	General Monitoring
B5	Solid Gel	Foam	Enhanced	43*46mm	General Monitoring
B4	Solid Gel	Foam	Enhanced	43*46mm	General Monitoring
B7	Solid Gel	Foam	Enhanced	50*50mm	Long Monitoring
B8	Solid Gel	Foam	Standard	30*30mm	Short Monitoring / Child
B9	Solid Gel	Foam	Standard	25.4*25.4mm	Short Monitoring / Infant
B10	Solid Gel	Soft Cloth	Standard	50*50mm	Short Monitoring
B13	Solid Gel	Microporous Tape	Standard	50*50mm	Short Monitoring
B16	Solid Gel	Foam	Standard	24*39mm	Adult/ Child
B17	Solid Gel	Foam	Standard	36*43mm	Short Monitoring
B7B	Solid Gel	Foam	Standard	32*38mm	Banana Plug Electrode
B26	Solid Gel	Foam	Standard	32*38mm	Short Monitoring/ Child

Item	Gel	Backing	Adhesive	Dimension	Usage
B12	Solid Gel	Foam	Enhanced	50*50mm	Stress Test/ Holter
B14	Solid Gel	Foam	Enhanced	50*55mm	Stress Test/ Holter
B18	Solid Gel	Foam	Enhanced	55*55mm	Trealmill Test/ Running Test
B24	Solid Gel	Foam	Enhanced	50*50mm	Stress Test/ Holter

Item	Gel	Backing	Adhesive	Dimension	Usage
B7C	Solid Gel	Foam	Standard	50*50mm	Radiology / Adult
B8C	Solid Gel	Foam	Standard	30*30mm	Radiology / Child

Item	Gel	Backing	Adhesive	Dimension	Usage
B5W	Wet Gel	Foam	Enhanced	43*46mm	Short Monitoring
B7W	Wet Gel	Foam	Enhanced	50*50mm	Short Monitoring

Item	Gel	Backing	Adhesive	Dimension	Usage
B19	hydro-gel	Soft Cloth	Standard	22*22mm	Neonatal
B20	hydro-gel	Foam	Standard	22*22mm	Neonatal

Item	Gel	Backing	Adhesive	Dimension	Usage
B22	Solid Gell	Foam	Standard	32*44mm	Short Monitoring
